Everlasting 5061L 1.50 Uni-Tandem Boiler Blowdown Valve Overview
The Everlasting 5061L 1.50 Uni-Tandem Boiler Blowdown Valve, officially designated ordering number 5061L-1.50, is a 1-1/2-inch Class 300 valve designed for controlled bottom blowdown service in industrial steam boiler systems.
The 5061L combines quick-opening and slow-opening functions in a single Uni-Tandem assembly. It features carbon steel construction, flanged connections, straight-through flow, and a maximum blow-off pressure of 490 PSI according to ASME Code.
The 5061L-1.50 has an 11.5-inch face-to-face dimension and weighs approximately 70 lb. Its combined quick/slow configuration is suitable for severe boiler blowdown applications involving scale, sludge, sediment, and repeated operating cycles.
